LR-200

Compare

LR-200 Transmitter Specifications

A bicycle-mounted transmitter for route tracking with a sentry mode – alerts triggered by movement of the monitored bicycle.

Power Supply

Built-in battery – Charged via USB port (5V, 1A)

Current Consumption

  • Minimum charging current: 0.5A
  • Maximum charging current: 1A
  • Average charging current: 0.6A

Operating Temperature Range

  • From -30°C to +50°C

Antennas

  • GSM antenna: Built-in
  • GNSS antenna: Built-in

Physical Specifications

  • Dimensions: 154 mm × 41 mm × 31 mm (excluding mounting)
  • Ingress protection rating: IP65
  • Weight: 150g (excluding mounting)

SIM Card Type

  • Nano SIM (4FF)

Memory and Sensors

  • Internal data memory: Up to 30,000 records

Built-in accelerometer: Motion detection

Battery

Built-in rechargeable battery: 3.7V, 2600mAh

Downloadable Files

Instrukcja
Real-time vehicle trackingGPS / GLONASS (built-in antenna)
Driver identification and/or authorization via RFID / DALLASno
Driver identification and/or authorization via Bluetooth (BT)no
Route playback✔
Trip history✔
Geofencing / zone monitoring✔
E-TOLL (electronic toll collection system)no
SENT GEO (Polish GPS-based monitoring system)no
ECO Driving (driver behavior evaluation)no
Reportsno
Digital tachograph (DDD files, driver card status/number – D8)no
Vehicle battery protection (automatic shutdown at low voltage)no
Alerts / Events✔
Mileage records✔ GPS
Vehicle start-block controlno
Remote door locking/unlocking (carsharing)no
Black box functionality (offline storage of up to 30,000 records)✔
Driving / parking mode switching✔ (motion sensor)
Tow/lift detection (via built-in accelerometer)no
TechnologyGSM, GPRS, LTE(4G), GNSS (GPS, GLONASS)
Power supplyBuilt-in battery – charged via USB port (5V, 1A)
Current consumption (min.)charging 0,5A
Current consumption (max.)charging 1A
Current consumption (avg.)charging 0,6A
Operating temperature range-30°C to +50°C
GSM antennaBuilt-in
GNSS antennaBuilt-in
Dimensions (W × L × H)154 mm × 41 mm × 31 mm (excluding mounting)
Enclosure protection classIP65
SIM card typeNano (4FF)
Internal data memory30,000 records
Built-in accelerometerMotion detection
Programming interface-
BatteryBuilt-in rechargeable battery, 3.7V, 2600mAh
Wejście ACC-
Inputs-
Interfaces-
Control Outputs-
